รายละเอียด ตลับลูกปืน McGill CAMROL® Crowned Inch Cam Follower - Stud Mount Roller - Screwdriver Slot - Sealed - CCF 3 S
General Specifications
| UPC: | 726166039301 | Weight: | 4.00 LB |
| Packaged Length: | 3.25 Inches | Packaged Width: | 3.25 Inches |
| Packaged Height: | 4.5 Inches | HTC: | 8482.40.0000 |
| Country of Origin: | Mexico |
Dimensions
| Crown Radius: | 30 | Threads: | 1 1/4-12 |
| Roller Diameter - Inch: | 3 | Stud Length - Inch: | 2.5 |
| Minimum Thread Length: | 1.25 | Lubrication Fitting Size - Metric: | 0.25 |
| Roller Width - Inch: | 1.75 | Oil Hole Center - Inch: | 0.625 |
| Stud Diameter - Inch: | 1.25 | Lubrication Fitting Size - Inch: | 0.25 |
Technical Specifications
| Hex/Slot: | Screwdriver Slot | Dynamic Radial Rating: | 15,720 |
| Sealing: | Sealed | O.D. Configuration: | Crowned |
| Adjustment: | None | Rolling Element: | Needle Roller - Full Complement |
| Limiting Speed: | 950 | Relubricatable: | Yes |
| Material: | Bearing Steel, Black Oxide Finish | Static Load Rating: | 24,910 |
| Clamping Torque - in-lbf: | 3,450 | Dynamic Load Rating - lb: | 15,720 |
| Tolerance Class: | P0 Equivalent | Platform: | CAMROL® |
| Stud Type: | Standard Stud | Roller Shape: | Crowned |
| Lubrication Hole Location: | Stud side |
