| Part | Material | Sizes |
|---|---|---|
| Body | Cast Iron BS EN 1561 GJL-250 | All |
| Cap | Cast Iron BS EN 1561 GJL-250 | All |
| Disc | Cast Iron BS EN 1561 GJL-250 | All |
| Body Seat Ring | Bronze BS EN 1982 CC491K | All |
| Disc Ring | Nitrile Rubber | All |
| Hinge Pin Bush | Bronze BS EN 1982 CC491K | All |
| Hinge Pin Plug | Bronze BS EN 1982 CC491K | All |
| Hinge Pin | Stainless Steel Type 304 | 50 - 80 |
| Hinge Pin | 13% Cr.Steel AISI Type 410 | 100 - 300 |
| Cap Bolts | Steel BS 3692 Gr.8.8 | All |
| Cap Bolt Nuts | Steel BS 3692 Gr.8 | All |
| Gasket | Asbestos Free | All |
| Body Plate | Aluminium | All |
| Disc Ring Retaining Nut | Cast Iron BS EN 1561 GJL-250 | All |
| Retaining Nut Pin | Steel | All |
Dimensions & Weights
| Size(DN) | Weight(Kg) | A(mm) | E(mm) |
|---|---|---|---|
| 50 | 11.3 | 203 | 113 |
| 65 | 15.6 | 216 | 126 |
| 80 | 19.3 | 241 | 136 |
| 100 | 26.6 | 292 | 153 |
| 125 | 44 | 330 | 186 |
| 150 | 55.5 | 356 | 207 |
| 200 | 119 | 495 | 250 |
| 250 | 175 | 622 | 352 |
| 300 | 263 | 698 | 397 |
