โซลินอยด์วาล์ว SMC Proportional Control Valve - Solenoid G 1/8 PVQ30 Series 24V dc

โซลินอยด์วาล์ว SMC Proportional Control Valve - Solenoid G 1/8 PVQ30 Series 24V dc

SMC

กรุณาตรวจสอบสต็อกก่อนชำระเงิน
4.00 ฿
4.00 ฿
ลดราคา ขายหมดแล้ว

รายละเอียด โซลินอยด์วาล์ว SMC Proportional Control Valve - Solenoid G 1/8 PVQ30 Series 24V dc

  • PVQ series, compact proportional solenoid valve, was designed by SMC with a direct poppet construction. This construction enables low leakage, while de-energized. PVQ series has been used in applications such as air blow, flow control, hand piece control for dental unit and other respiratory equipment, as well as cooling for laser machinery etc
Specifications
Manufacturer Series PVQ30
Mounting Style Body Ported
Connection Port Thread G 1/8
Actuation Type Solenoid
Body Material C37
Maximum Flow Rate 100L/min
Solenoid Voltage 24V dc
Solenoid Power Consumption 4W
Minimum Operating Pressure 0MPa
Minimum Operating Temperature 0°C
Thread Size 1/8in
Maximum Operating Pressure 1 MPa
Maximum Operating Temperature +50°C
Configuration Normally Closed
Number of Ports 2
Number of Positions 2
Special Features Direct Operated Poppet Construction, Hysteresis 10 % or Less, Repeatability 3 % or Less, Start-Up Current 50 % or Less
Thread Standard G
