Turck Inductive Block-Style Proximity Sensor รหัส BIM-IKT-AP6X
Turck Inductive Block-Style Proximity Sensor รหัส BIM-IKT-AP6X
TURCK
กรุณาตรวจสอบสต็อกก่อนชำระเงินราคาปกติ
3,143.00 ฿
ราคาปกติ
3,698.00 ฿
ราคาโปรโมชัน
3,143.00 ฿
ราคาต่อหน่วย
ต่อ
ไม่สามารถโหลดความพร้อมในการรับสินค้าด้วยตนเองได้
รายละเอียด Turck Inductive Block-Style Proximity Sensor รหัส BIM-IKT-AP6X
Turck Extruded Tie Rod and Profile Cylinder Sensors
Features and benefits
Zinc die-cast housing protected to IP67
Designed for use with double rail, tie rod, profile and extruded with external dovetail guide cylinders using Turck Mounting Brackets
Isolation barriers are available separately
Overload, short circuit and reverse polarity protection
LED Status Display
Turck Proximity Sensor, Block Body Style, IP67 - BIM-IKT-AP6X
This Turck proximity sensor is an inductive sensor designed for industrial applications in the automation, electronics, electrical, and mechanical industries. With a high switching frequency of 1 kHz, IP67 rating, and PNP output, this sensor ensures reliable performance in various environments. It boasts a non flush mounting design and features a housing made of gadolinium zinc, making it durable and suitable for demanding industrial settings.
Features & Benefits
• Reliable inductive Sensor Technology
• IP67 Rated for Dust and Waterproofing
• PNP Output for Easy integration
• Short Circuit Protection for Enhanced Safety
• Wide Operating Temperature Range ( 25°C to +70°C)
• High Switching Frequency for Quick Response Time
• IP67 Rated for Dust and Waterproofing
• PNP Output for Easy integration
• Short Circuit Protection for Enhanced Safety
• Wide Operating Temperature Range ( 25°C to +70°C)
• High Switching Frequency for Quick Response Time
Applications
• Ideal for piston position detection in pneumatic cylinders
• Suitable for automation systems requiring precise detection
• Used in machinery to ensure proper positioning
• Perfect for industrial control systems for reliable performance
• Suitable for automation systems requiring precise detection
• Used in machinery to ensure proper positioning
• Perfect for industrial control systems for reliable performance
Can it withstand harsh industrial environments?
The Turck proximity sensor is IP67 rated, ensuring protection against dust and water ingress, making it suitable for use in rugged industrial settings.
Will it work in extreme temperatures?
With an operating temperature range from -25°C to +70°C, this sensor is designed to function reliably in various temperature conditions.
Is it easy to integrate into existing automation systems?
Yes, the sensor features a PNP output type, making it compatible with a wide range of industrial control systems for seamless integration.
Can it detect objects accurately in fast-moving machinery?
The high switching frequency of 1 kHz ensures quick response time for precise object detection, making it suitable for fast-moving machinery applications.
What safety features does the sensor have?
The sensor comes with short circuit protection, providing an extra layer of safety in case of electrical faults.
คุณสมบัติ |
Value |
|---|---|
| Sensor Technology | Inductive |
| Body Style | Block |
| Thread Size | M12 x 1 |
| Output Type | PNP-NO |
| Terminal Type | Cable |
| Supply Voltage | 10 → 30 V dc |
| IP Rating | IP67 |
| Length | 30mm |
| Width | 14.6mm |
| Switching Frequency | 1 kHz |
| Depth | 17mm |
| Maximum DC Voltage | 30V |
| Mounting Type | Non Flush |
| Switching Current | 200 mA |
| Housing Material | Gadolinium Zinc |
| Maximum Operating Temperature | +70°C |
| Maximum Switching Frequency | 1kHz |
| Short Circuit Overload Protection | Yes |
| Minimum Operating Temperature | -25°C |
| Reverse Polarity Protection | Yes |
