Turck Inductive Barrel-Style Proximity Sensor รหัส NI12U-EG18SK-AN6X
Turck Inductive Barrel-Style Proximity Sensor รหัส NI12U-EG18SK-AN6X
TURCK
กรุณาตรวจสอบสต็อกก่อนชำระเงินราคาปกติ
4,645.00 ฿
ราคาปกติ
5,465.00 ฿
ราคาโปรโมชัน
4,645.00 ฿
ราคาต่อหน่วย
/
ต่อ
ไม่สามารถโหลดความพร้อมในการรับสินค้าด้วยตนเองได้
รายละเอียด Turck Inductive Barrel-Style Proximity Sensor รหัส NI12U-EG18SK-AN6X
Threaded Barrel Block Body Sensor
The Uprox range of inductive proximity sensors from Turk offer durability and a high degree of accuracy. The sensors body is made from stainless steel (1.4201), the sensing face is a resistant PBT plastic. This range of inductive proximity sensors from Turk can be used in a variety of applications due to its extreme resistance to environmental influences. The range also features factor 1 sensing for all metals allowing for a wider range of uses.
Predamping protection through self compensation
Factor1 sensing ability for all metals
Immune to magnetic interference
Factor1 sensing ability for all metals
Immune to magnetic interference
Uprox Range
Extended sensing ranges
Sense all metals at the same distance - with no reduction factor
IP67 rating (Barrel is IP68)
High switching frequency
No load current 15mA max.
Operating Temperature Range -25 → +85°C
Short circuit protection Overload protection
Reverse polarity protection
Inherent weld field immunity
Sense all metals at the same distance - with no reduction factor
IP67 rating (Barrel is IP68)
High switching frequency
No load current 15mA max.
Operating Temperature Range -25 → +85°C
Short circuit protection Overload protection
Reverse polarity protection
Inherent weld field immunity
คุณสมบัติ |
Value |
|---|---|
| Sensor Technology | Inductive |
| Body Style | Barrel |
| Thread Size | M18 x 1 |
| Output Type | NPN-NO |
| Detection Range | 12 mm |
| Terminal Type | PG9 Gland |
| Supply Voltage | 10 → 30 V dc |
| IP Rating | IP68 |
| Length | 77mm |
| Depth | 29mm |
| Maximum DC Voltage | 30V |
| Mounting Type | Non Flush |
| Switching Current | 200 mA |
| Shielding | Partial |
| Maximum Switching Frequency | 2kHz |
| Housing Material | Metal |
| Maximum Operating Temperature | +85°C |
| Short Circuit Overload Protection | Yes |
| Minimum Operating Temperature | -30°C |
| Reverse Polarity Protection | Yes |
