Linear Bushing LMCF20L

Linear Bushing LMCF20L

THK

กรุณาตรวจสอบสต็อกก่อนชำระเงิน

1,708.00 ฿

1,708.00 ฿

ลดราคา ขายหมดแล้ว

ปริมาณ

รายละเอียด Linear Bushing LMCF20L

Model No.	Ball rows	Main dimensions														Flangeperpen-dicularity	Eccentricity(max)	Radial Clearance Tolerance	Basic load rating		Mass
		Inscribed bore diameter		Outer diameter		Overall length		Flange diameter		Pilot		D₂	H	PCD	Mounting holed₁×d₂×h				Dynamic C	Static C₀
		dr	Tolerance	D	Tolerance	L	Tolerance	D₁	Tolerance	I	Tolerance	D₂	H	PCD	Mounting holed₁×d₂×h				Dynamic C	Static C₀
		mm		mm		mm		mm		mm		mm	mm	mm	mm	µm	µm	µm	N	N	g
LMCF6L	4	6	0-0.010	12	0-0.013	35	±0.3	28	0-0.2	15	±0.2	12	15	20	3.4×6×3.3	12	12	-5	324	529	30
LMCF8L	4	8		15	0-0.013	45		32		20		15	20	24	3.4×6×3.3	12	12	-5	431	784	46
LMCF10L	4	10		19	0-0.016	55		39		24.5		19	24.5	29	4.5×7.5×4.4	12	12	-5	588	1100	83
LMCF12L	4	12		21		57		42		25.5		21	25.5	32	4.5×7.5×4.4	12	12	-5	657	1200	95
LMCF13L	4	13		23		61		43		27.5		23	27.5	33	4.5×7.5×4.4	12	12	-7	814	1570	117
LMCF16L	5	16		28		70		48		32		28	32	38	4.5×7.5×4.4	12	12	-7	1230	2350	196
LMCF20L	5	20	0-0.012	32	0-0.019	80		54		36		32	36	43	5.5×9×5.4	15	15	-9	1400	2750	244
LMCF25L	6	25	0-0.012	40	0-0.019	112		62		52		40	52	51	5.5×9×5.4	15	15	-9	1560	3140	498
