• Carlo Gavazzi Voltage Monitoring Relay Code DUB01CD48500V
1 1

Carlo Gavazzi Voltage Monitoring Relay Code DUB01CD48500V

Carlo Gavazzi Voltage Monitoring Relay Code DUB01CD48500V

รูปสินค้าอาจไม่ตรงกับของจริง รบกวนสอบถามแอดมินเพื่อขอดูรูปเพิ่มเติม

CARLO GAVAZZI

กรุณาตรวจสอบสต็อกก่อนชำระเงิน
6,242.00 ฿
7,344.00 ฿ 6,242.00 ฿
ลดราคา ขายหมดแล้ว

รายละเอียด Carlo Gavazzi Voltage Monitoring Relay Code DUB01CD48500V

Single Phase Load Monitoring Relay


Carlo Gavazzi DUB01 & PUB01 series of monitoring relays provide the user with a precise TRMS AC/DC over & under voltage monitoring options controlled by DIP switches. LED indication of status changes make simple recognition

TRMS AC/DC over & under voltage monitoring relay solution
DIP switch selection
LED indication for relay, alarm and power supply ON
SPDT contact configuration
Suitable for DIN mounting


คุณสมบัติ
Value
Monitoring Application Voltage
Electrical Phase 1
Contact Configuration SPDT
Voltage Sensing Range 2 → 500V ac/dc
Voltage Sensitivity Overvoltage, Undervoltage
Mounting Type DIN Rail
Time Delay 1 s, 6s
Series DUB01
Minimum Operating Temperature -20°C
Dimensions 99.5 x 22.5 x 80mm
Width 22.5mm
Maximum Operating Temperature +60°C
Minimum Voltage Sensed 2V ac/dc
Length 99.5mm
Operating Temperature Range +60°C
Height 80mm
Maximum Voltage Sensed 500V ac/dc


Datasheet - EM530DINAV53XM1PFA
