• Burkert Solenoid Valve 064512, 2 port(s) , NC, 24 V dc, 1/4inRS Stock No.:468-273หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:064512
1 1

Burkert Solenoid Valve 064512, 2 port(s) , NC, 24 V dc, 1/4inRS Stock No.:468-273หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:064512

Burkert Solenoid Valve 064512, 2 port(s) , NC, 24 V dc, 1/4inRS Stock No.:468-273หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:064512

13,078.00 ฿
16,348.00 ฿ 13,078.00 ฿
ลดราคา ขายหมดแล้ว

Burkert

รายละเอียด Burkert Solenoid Valve 064512, 2 port(s) , NC, 24 V dc, 1/4inRS Stock No.:468-273หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:064512

PP and PVDF, 2 and 3 way, Type 124

Solenoid valves with pivoted armatures.

Lockable manual over-ride
3-pin DIN connector rated to IP65 can be positioned through 360° in 90° increments
Duty cycle intermittent operation 40% 30 min
8W nominal coil power
Power consumption 30VA (in-rush), 15 VA/8W (hold) a.c, A 8W d.c.
Zero head pressure capability
Fluid temperature range: -30 → +80°C (EPDM), 0 → +80°C (FKM)
Suitable for: alkalis and acids to medium concentration; alkaline washing and bleaching agents
Note
BSP parallel ports suitable for use with RS stainless steel compression fittings
คุณสมบัติ Value
Supply Voltage 24 V dc
Number of Ports 2
Connection Size 1/4in
Connection 1/4 in G Female
Operation Direct
Default Valve Position NC
Suitable Applications Aggressive Media
Type 2/2
Orifice Diameter 5mm
Body Material PVDF
Series 0124
Maximum Working Pressure 3 bar
Operating Temperature Range Maximum of +55 °C
Maximum Operating Temperature +55°C
Connection Gender Female
Thread Standard or Connection Type G
Flow Factor Kv 0.4m³/h
