รายละเอียด Banner T18 Series Self-Contained Barrel-Mount Sensor Code S18SN6FF50 W/30
Specifications
| IP Rating | IP67, IP69K |
| Sensing Beam | Infrared LED |
| Power | DC |
| Sensing Mode (General) | Opposed |
| Sensing Mode (Detailed) | Emitter |
| Housing Style | Barrel |
| Primary Housing Material | Thermoplastic |
| Max Sensing Distance (mm) | 20000 |
| Power Supply/Supply Voltage | 10-30 V dc |
| Connection | Integral QD |
| Quick Disconnect Type | M12 |
| Min Op. Temp. (°C) | -40 |
| Operation | N/A |
| Max Op. Temp. (°C) | 70 |
| Output response time (ms) | N/A |
| Special Feature: Intrinsically Safe | No |
| Special Feature: Remote Teach | No |
| Special Feature: Water Detection | No |
| Delay at Power-up (ms) | 100 |
| Repeatability (µs) | 375 |
| Number of Pins | 4 |
| NEMA Rating | NEMA 6P |
| Max Op. Relative Humidity [%] | 90% @ 50°C |
| Lens Material | Polycarbonate |
| Adjustments | N/A |
| Barrel Diameter (mm) | 18 |
| Indicator | LEDs |
| Opposed Mode Emitter/Receiver | Emitter |
| Feature: Washdown Rated | Yes |
| Feature: Ecolab Certified | Yes | Feature: Encapsulated | Yes | Feature: Audible | No | Feature: Chemical Resistant | Yes | Feature: Quick Disconnect | Yes | Feature: Health/ Marginal Signal Output | Yes |
