รายละเอียด ตลับลูกปืน McGill Heavy Stud CAMROL® Cylindrical Inch Cam Follower - Stud Mount Roller - Hex Hole - Sealed - CFH 1/2 SB
General Specifications
| UPC: | 726166030049 | Weight: | 0.04 LB |
| Packaged Length: | 4 Inches | Packaged Width: | 4 Inches |
| Packaged Height: | 3 Inches | HTC: | 8482.40.0000 |
| Country of Origin: | Mexico |
Dimensions
| Threads: | 1/4-28 | Minimum Thread Length - Inch: | 0.25 |
| Roller Diameter - Inch: | 0.5 | Stud Length - Inch: | 0.625 |
| Roller Width - Inch: | 0.375 | Stud Diameter - Inch: | 0.25 |
Technical Specifications
| O.D. Configuration: | Cylindrical | Hex/Slot: | Hex Hole |
| Limiting Speed: | 11,500 | Rolling Element: | Needle Roller - Full Complement |
| Sealing: | Sealed | Adjustment: | None |
| Relubricatable: | No | Material: | Bearing Steel, Black Oxide Finish |
| Platform: | CAMROL® | Static Load Rating: | 600 |
| Roller Shape: | Cylindrical | Stud Type: | Heavy Stud |
| Clamping Torque - in-lbf: | 35 | Tolerance Class: | P0 Equivalent |
| Dynamic Load Rating - lb: | 680 |
