TL-W3 Inductive Sensors
Features and benefits
Space saving, low profile rigid aluminium die cast housing
All provided with an operation indicator
Mounting front or rear of the housing
Protected from water or oil splashes
Standards
IEC IP67
Standards
IEC IP67
Specifications
| คุณสมบัติ |
Value |
| Sensor Technology |
Inductive |
| Body Style |
Block |
| Output Type |
NPN-NO |
| Detection Range |
3 mm |
| Terminal Type |
Cable |
| Supply Voltage |
12 → 24 V dc |
| IP Rating |
IP67 |
| Length |
27mm |
| Width |
10mm |
| Maximum DC Voltage |
30V |
| Mounting Type |
Non Flush |
| Switching Current |
100 mA |
| Maximum Operating Temperature |
+70°C |
| Shielding |
Unshielded |
| Maximum Switching Frequency |
600Hz |
| Housing Material |
ABS Resin |
| Reverse Polarity Protection |
Yes |
| Minimum Operating Temperature |
-25°C |
