Class of Fit : 2B
Dimensions Standard : ISO 529
Finish/Coating : Steam Tempered
Helix Angle : 45 °
Material : High Speed Steel
Material Application : Aluminium
Material Application : Cast Iron
Material Application : Stainless Steel
Material Application : Steel
Material Grade : M2
Number of Flutes : 3
Overall Length : 85 mm
Pitch : 20
Series : N/A
Shank Diameter : 8 mm
Square Width : 6.3 mm
Tap Type : Spiral Flute
Tapping Depth : N/A mm
Thread Direction : Right Hand
Thread Length : 25 mm
Thread Size : 7/16"
Thread Standard : UNF
