รายละเอียด ตลับลูกปืน McGill CAMROL® Cylindrical Inch Cam Follower - Stud Mount Roller - Hex Hole - Sealed - CF 1 3/4 SB
General Specifications
| UPC: | 726166036492 | Weight: | 0.83 LB |
| Packaged Length: | 2 Inches | Packaged Width: | 2 Inches |
| Packaged Height: | 2.87 Inches | HTC: | 8482.40.0000 |
| Country of Origin: | Mexico |
Dimensions
| Threads: | 3/4-16 | Lubrication Fitting Size - Metric: | 0.1875 |
| Roller Diameter - Inch: | 1.75 | Stud Length - Inch: | 1.75 |
| Roller Width - Inch: | 1 | Minimum Thread Length: | 0.875 |
| Stud Diameter - Inch: | 0.75 | Hex Socket - Inch: | 0.3125 |
| Lubrication Fitting Size - Inch: | 0.1875 |
Technical Specifications
| Limiting Speed: | 2,200 | O.D. Configuration: | Cylindrical |
| Rolling Element: | Needle Roller - Full Complement | Sealing: | Sealed |
| Hex/Slot: | Hex Hole | Dynamic Radial Rating: | 6,385 |
| Adjustment: | None | Relubricatable: | Yes |
| Material: | Bearing Steel, Black Oxide Finish | Platform: | CAMROL® |
| Stud Type: | Standard Stud | Roller Shape: | Cylindrical |
| Clamping Torque - in-lbf: | 1,250 | Dynamic Load Rating - lb: | 6,385 |
| Static Load Rating: | 6,000 | Tolerance Class: | P0 Equivalent |
